Redway Battery lithium battery (Sealed Lead Acid Replacement / SLAR) offers many advantages over traditional lead-acid batteries. Due to its longer cycle life, higher discharge rate, and improved performance at low temperatures, it is a more reliable and economical choice for many applications. Additionally, its lighter weight and compact design make it easier to carry and install, allowing your device to travel farther and reducing the time it takes to fully charge. Lithium batteries have a greener impact on the environment compared to Sealed Lead Acid batteries. Redway Battery offers a full range of lithium batteries in BCI Group 24, Group 27, Group 31, Group 34, Group 35, Group 51, Group 51R, Group 78, Group 8D dimensions, etc. Redway Battery is a professional lithium battery factory . We undertake OEM/ODM/White Label production of lithium batteries and offer wholesale services, contact us.
| Items | Specification |
|---|---|
| Cell Type | LiFePO4 (Customizable: LiFePO4 / NCM / Prismatic / Cylindrical) |
| Nominal Voltage | 25.6V |
| Battery Capacity | 100Ah |
| Nominal Energy | 2.56kWh (2560Wh) |
| Dimension [L*W*H] | ① 277*174*189 mm (10.9*6.85*7.44 inch) Group 34 / Group 78 ② 522*240*218 mm (20.55*9.45*8.58 inch) (Customizable Dimension) |
| Weight | ≈19kg (41.88 lbs) |
| Working Voltage | 20V~29.2V |
| Charge Voltage | 29.2V |
| Discharge Cut-off Voltage | 20V |
| Maximum Charge Current | 100A Continuous |
| Maximum Discharge Current | 100A Continuous |
| Fast Charging | Supports Fast Charging |
| Charging Temperature | 0~60°C (32℉~140℉) |
| Discharging Temperature | -20~65°C (-4℉~149℉) |
| Operating Humidity Range | <75% |
| Internal Resistance | ≤30mΩ |
| Terminal | M8 |
| Series/Parallel Number | 8S7P |
| Max. Parallel Connection | 4 |
| Cycle Life (25°C / 77℉@60% DOD) | >8000 Cycles |
| Cycle Life (25°C / 77℉@80% DOD) | >6000 Cycles |
| Self-Discharge Rate | <3% per month (25°C / 77℉) |
| IP Grade | IP65 (Higher grade optional) |
| Battery Case | ABS |
| Monitoring & Protection | Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit |
| Optional Functions | Bluetooth / WiFi / Communication (RS485, CAN, etc) / Heating / Active Balance / Switch / LCD Screen / LED Touch Screen / APP |
| Optional Accessories | Charger, Parallel Cable, Communication Cable, Grounding Wire, etc. |
| Design Life | 10 Years |
| Warranty | 5 Years |
| User Manual | With the Battery Packaging |
| Certification & Safety Standard | UL / FCC / CE / IEC / RoHS / UN38.3 / MSDS |
